> Why are Door Bolts Pointy?, P/N 111899145
Highland
post Aug 12 2019, 07:08 PM
Post #1


Senior Member
***

Group: Members
Posts: 550
Joined: 8-August 11
From: San Diego, CA
Member No.: 13,418
Region Association: Southern California
Was wondering why the door bolts are pointy. Can I replace them with standard M8 X 22 coarse thread bolts? I know they're listed as 27 mm, but I assume that includes the point.

Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post

 Reply to this topicStart new topic
Replies(1 - 17)
Superhawk996
post Aug 12 2019, 07:14 PM
Post #2


914 Guru
*****

Group: Members
Posts: 7,219
Joined: 25-August 18
From: Woods of N. Idaho
Member No.: 22,428
Region Association: Galt's Gulch
In a manufacturing environment pointy or dog head bolts allow power tools to drive the fastener quicker and better with power tools. The point helps the bolt find center quickly and reduces the risk of cross threading without having to hand start bolts.

I have no idea how Porsche assembled back in the day, but, it's likely Hans held the door in position and Franz drove the bolts quickly with an air tool as Hans complained that it was about time to swap jobs and Franz should hold some doors in position. (IMG:style_emoticons/default/happy11.gif)

Probably rough fit to hold in position 1st and tweaked later.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
TargaToy
post Aug 12 2019, 07:28 PM
Post #3


-NONSOLIS RADIOS SEDIOUIS FULMINA MITTO-
***

Group: Members
Posts: 713
Joined: 26-March 10
From: DelMarVa Peninsula
Member No.: 11,509
Region Association: MidAtlantic Region
So your bung hole doesn’t slam shut!

Oh, sorry. I thought you asked why turds are pointy...
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Superhawk996
post Aug 12 2019, 07:31 PM
Post #4


914 Guru
*****

Group: Members
Posts: 7,219
Joined: 25-August 18
From: Woods of N. Idaho
Member No.: 22,428
Region Association: Galt's Gulch
(IMG:style_emoticons/default/av-943.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
bbrock
post Aug 12 2019, 08:22 PM
Post #5


914 Guru
*****

Group: Members
Posts: 5,269
Joined: 17-February 17
From: Montana
Member No.: 20,845
Region Association: Rocky Mountains
Pointy also makes it easier for a one-person door install with a hand socket. The self centering bolt is just what you need to hold the door with one arm and get a bolt started in the top hinge with a socket wrench. Doing that with a regular bolt wouldn't be impossible, but a lot harder and greater chance for cross threading.

Oh - and also so your bunghole doesn't slam shut. (IMG:style_emoticons/default/happy11.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
mepstein
post Aug 12 2019, 08:40 PM
Post #6


914-6 GT in waiting
***************

Group: Members
Posts: 19,963
Joined: 19-September 09
From: Landenberg, PA/Wilmington, DE
Member No.: 10,825
Region Association: MidAtlantic Region
https://vwparts.aircooled.net/Floor-Pan-Bol...111-899-145.htm

$.95 each
User is online!Profile CardPM
Go to the top of the page
+Quote Post
IronHillRestorations
post Aug 12 2019, 09:49 PM
Post #7


I. I. R. C.
*****

Group: Members
Posts: 6,831
Joined: 18-March 03
From: West TN
Member No.: 439
Region Association: None
The reason they have a point is because the nut plate they bolt into floats in it's bracket in the door jamb and the point guides the bolt into the threaded boss in the nut plate.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
raynekat
post Aug 12 2019, 10:12 PM
Post #8


Advanced Member
****

Group: Members
Posts: 2,169
Joined: 30-December 14
From: Coeur d'Alene, Idaho
Member No.: 18,263
Region Association: Pacific Northwest
QUOTE(IronHillRestorations @ Aug 12 2019, 08:49 PM) *

The reason they have a point is because the nut plate they bolt into floats in it's bracket in the door jamb and the point guides the bolt into the threaded boss in the nut plate.


Yeah....I like this answer the best. Whatever floats your bolt!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
rgalla9146
post Aug 13 2019, 04:35 AM
Post #9


Advanced Member
****

Group: Members
Posts: 4,777
Joined: 23-November 05
From: Paramus NJ
Member No.: 5,176
Region Association: None
QUOTE(Highland @ Aug 12 2019, 09:08 PM) *

Was wondering why the door bolts are pointy. Can I replace them with standard M8 X 22 coarse thread bolts? I know they're listed as 27 mm, but I assume that includes the point.

Attached Image


Not on early cars.
For ease of assembly.
Have you seen what fasteners look like in modern cars ?
All are tailored for powered/robotic assembly.
User is online!Profile CardPM
Go to the top of the page
+Quote Post
Krieger
post Aug 13 2019, 07:46 AM
Post #10


Advanced Member
****

Group: Members
Posts: 4,808
Joined: 24-May 04
From: Santa Rosa CA
Member No.: 2,104
Region Association: None
Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Superhawk996
post Aug 13 2019, 08:52 AM
Post #11


914 Guru
*****

Group: Members
Posts: 7,219
Joined: 25-August 18
From: Woods of N. Idaho
Member No.: 22,428
Region Association: Galt's Gulch
QUOTE(rgalla9146 @ Aug 13 2019, 06:35 AM) *

QUOTE(Highland @ Aug 12 2019, 09:08 PM) *

Was wondering why the door bolts are pointy. Can I replace them with standard M8 X 22 coarse thread bolts? I know they're listed as 27 mm, but I assume that includes the point.

Attached Image


Not on early cars.
For ease of assembly.
Have you seen what fasteners look like in modern cars ?
All are tailored for powered/robotic assembly.


Spot on.

Modern fasteners are designed for manufacturing. Notice many modern fasteners also have captive washers. Avoids wasted time and lost $$ being scattered on the floor from dropped parts as a line operator tries to put a washer on the fastener. Also ensures they don't forget to put on the washer.

Here's a picture of modern bolt with dog point and a captive washer.

Much less likely to cross thread than the pointed bolt in OP.

Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Mark Henry
post Aug 13 2019, 06:44 PM
Post #12


that's what I do!
***************

Group: Members
Posts: 20,065
Joined: 27-December 02
From: Port Hope, Ontario
Member No.: 26
Region Association: Canada
QUOTE(TargaToy @ Aug 12 2019, 09:28 PM) *

So your bung hole doesn’t slam shut!

Oh, sorry. I thought you asked why turds are pointy...

I'm still trying to perfect the perfect pinch.
That's when you pinch off a loaf so cleanly that you don't have to wipe.

TMI (IMG:style_emoticons/default/confused24.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
TonyA
post Aug 14 2019, 01:39 PM
Post #13


Nachmal
***

Group: Members
Posts: 614
Joined: 17-November 16
From: Hilltown PA
Member No.: 20,596
Region Association: North East States
QUOTE(Mark Henry @ Aug 13 2019, 08:44 PM) *

QUOTE(TargaToy @ Aug 12 2019, 09:28 PM) *

So your bung hole doesn’t slam shut!

Oh, sorry. I thought you asked why turds are pointy...

I'm still trying to perfect the perfect pinch.
That's when you pinch off a loaf so cleanly that you don't have to wipe.

TMI (IMG:style_emoticons/default/confused24.gif)


Great technique to use while camping!!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
malcolm2
post Aug 14 2019, 02:03 PM
Post #14


Advanced Member
****

Group: Members
Posts: 2,747
Joined: 31-May 11
From: Nashville
Member No.: 13,139
Region Association: South East States
QUOTE(Mark Henry @ Aug 13 2019, 07:44 PM) *

QUOTE(TargaToy @ Aug 12 2019, 09:28 PM) *

So your bung hole doesn’t slam shut!

Oh, sorry. I thought you asked why turds are pointy...

I'm still trying to perfect the perfect pinch.
That's when you pinch off a loaf so cleanly that you don't have to wipe.

TMI (IMG:style_emoticons/default/confused24.gif)


Change your diet

KETO and Atkins..... Lots of cheese and protein.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
eatpez
post Sep 11 2019, 07:36 PM
Post #15


Newbie
*

Group: Members
Posts: 18
Joined: 4-October 18
From: Michigan
Member No.: 22,543
Region Association: North East States
Does anyone know if these bolts are M8x1.00 or M8x125? I pulled them out of my project car and I honestly can't tell for sure with the thread guide. I want to chase the threads in the plates but obviously don't want to screw that up.

The link to the VW chassis bolts shows M8x125 but I'd swear the ones that go back in easily are M8x1.00.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
eatpez
post Sep 11 2019, 07:47 PM
Post #16


Newbie
*

Group: Members
Posts: 18
Joined: 4-October 18
From: Michigan
Member No.: 22,543
Region Association: North East States
QUOTE(eatpez @ Sep 11 2019, 09:36 PM) *

Does anyone know if these bolts are M8x1.00 or M8x125? I pulled them out of my project car and I honestly can't tell for sure with the thread guide. I want to chase the threads in the plates but obviously don't want to screw that up.

The link to the VW chassis bolts shows M8x125 but I'd swear the ones that go back in easily are M8x1.00.



Definitely M8x1.25. The passenger side all went in fine. Now for some careful thread restoration....
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Highland
post Sep 11 2019, 09:48 PM
Post #17


Senior Member
***

Group: Members
Posts: 550
Joined: 8-August 11
From: San Diego, CA
Member No.: 13,418
Region Association: Southern California
Were the original door bolts painted in the car's color or plated?
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
mepstein
post Sep 12 2019, 04:35 AM
Post #18


914-6 GT in waiting
***************

Group: Members
Posts: 19,963
Joined: 19-September 09
From: Landenberg, PA/Wilmington, DE
Member No.: 10,825
Region Association: MidAtlantic Region
QUOTE(Highland @ Sep 11 2019, 11:48 PM) *

Were the original door bolts painted in the car's color or plated?

Painted
User is online!Profile CardPM
Go to the top of the page
+Quote Post
