Starting a new thread in response to @emeryGT 350 comment in another thread as follow up

Here’s the background:
Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post

Reply to this topicStart new topic
Replies
windforfun
post Jun 24 2024, 08:40 PM
Post #2


Advanced Member
****

Group: Members
Posts: 2,057
Joined: 17-December 07
From: Blackhawk, CA
Member No.: 8,476
Region Association: None



Copy that. The power supply reads out to one place & your DMM reads out to two places.

The DMM is more precise & only more more accurate if it's calibrated.

Precision & accuracy are not the same.

User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Superhawk996
post Jun 24 2024, 10:18 PM
Post #3


914 Guru
*****

Group: Members
Posts: 7,219
Joined: 25-August 18
From: Woods of N. Idaho
Member No.: 22,428
Region Association: Galt's Gulch



QUOTE(windforfun @ Jun 24 2024, 10:40 PM) *

Copy that. The power supply reads out to one place & your DMM reads out to two places.

The DMM is more precise & only more more accurate if it's calibrated.

Precision & accuracy are not the same.

Yup

Former USAF electronics tech. Fully familiar with using a $3000 (in 1980s dollars) HP bench DMM with resolution to the 4th decimal place with fully traceable calibration to measure a stupid 9v battery.

No need for that type of accuracy or precision for automotive hobby work.

Even working on complicated electronics it was very rare to ever need that level of accuracy and precision. Flukes were disposed of like toilet paper (IMG:style_emoticons/default/sad.gif)

The sad joke was that if you were going to break or lose a piece of test equipment, make sure it was something big and expensive like a $12k O-scope or $30k spectrum analyzer. They can withhold a Fluke out of your check via GPLD if they felt so inclined (Government property Lost or Damaged) but when you made $12k a year; they were never going to recoup something expensive.
