> Go Big or Go Home: Clay's 914-6, MS3Pro Wiring in Progress
Should I paint the flat fan shroud?
Paint or not
Paint it Red to match the car [ 15 ] ** [24.19%]
Paint it some other color. [ 3 ] ** [4.84%]
Leave it the current amber fiberglass color [ 44 ] ** [70.97%]
Total Votes: 62
Guests cannot vote
horizontally-opposed
post Aug 29 2019, 08:48 PM
Post #181


Advanced Member
****

Group: Members
Posts: 3,430
Joined: 12-May 04
From: San Francisco
Member No.: 2,058
Region Association: None
QUOTE(ClayPerrine @ Aug 29 2019, 07:45 PM) *



Only missing one oil line, from the engine to the right cooler. I have it, but we made it a little too long. So I have to take it and get the fitting crimped back on.


I actually took this picture after sitting on the garage floor, looking up at the engine and trans, and thinking "I can't believe we actually did this!" (IMG:style_emoticons/default/wacko.gif)


Digging the twin-cooler setup...and can't wait to hear how this thing drives. Biggest six I've tried was a 3.8, and it was a beast.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Aug 29 2019, 08:54 PM
Post #182


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
QUOTE(horizontally-opposed @ Aug 29 2019, 09:48 PM) *

QUOTE(ClayPerrine @ Aug 29 2019, 07:45 PM) *



Only missing one oil line, from the engine to the right cooler. I have it, but we made it a little too long. So I have to take it and get the fitting crimped back on.


I actually took this picture after sitting on the garage floor, looking up at the engine and trans, and thinking "I can't believe we actually did this!" (IMG:style_emoticons/default/wacko.gif)


Digging the twin-cooler setup...and can't wait to hear how this thing drives. Biggest six I've tried was a 3.8, and it was a beast.


The twin cooler setup was to make sure it runs cool. A friend as a stock 993 engine in his 914-6, and he is OK temp wise on the street, but at a DE he can't complete the session without overheating. He only has one cooler on the car, in the back like I have. The coolers I have are factory 964/993 coolers. Porsche put one on a 964, but it is up front in the cool air flow. Hopefully doubling the size will allow it to run cool even under extended load.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
wvspin2
post Aug 29 2019, 10:42 PM
Post #183


Newbie
*

Group: Members
Posts: 25
Joined: 29-December 17
From: Texas
Member No.: 21,737
Region Association: None
Wow great engineering it looks like its always belonged in there. Can't wait to see this perform. (IMG:style_emoticons/default/popcorn[1].gif) (IMG:style_emoticons/default/cheer.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Aug 30 2019, 06:51 AM
Post #184


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
QUOTE(ClayPerrine @ Aug 29 2019, 09:45 PM) *

I actually took this picture after sitting on the garage floor, looking up at the engine and trans, and thinking "I can't believe we actually did this!" (IMG:style_emoticons/default/wacko.gif)


This morning I looked at the picture, and thought "What the F**K have I done?" (IMG:style_emoticons/default/unsure.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Aug 31 2019, 06:44 AM
Post #185


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
Update: Last night I completed the oil system. The one remaining line was installed, and the system filled. 13 quarts in the tank and sump. Then I spun it over until I had oil pressure. Found I had switched the wires between the oil light sender and the oil pressure gauge. Swapped them and now I can see that I get above 30 psi when cranking.

Working on the brake and clutch systems today. Then the tank goes back in and I start it up!!!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rob-O
post Aug 31 2019, 07:16 AM
Post #186


Senior Member
***

Group: Members
Posts: 1,251
Joined: 5-December 03
From: Mansfield, TX
Member No.: 1,419
Region Association: Southwest Region
How exciting! So close!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
jdamiano
post Aug 31 2019, 07:51 AM
Post #187


Member
**

Group: Members
Posts: 335
Joined: 18-March 18
From: Jacksonville
Member No.: 21,981
Region Association: South East States
I’m looking forward to Octeenerfest for several reasons, seeing this being one of them. Clay might be able to charge for rides. This one looks like an E ticket for sure!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Aug 31 2019, 09:23 PM
Post #188


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
Today was not a good day in the land of Big Sixes.....

Tried to start the motor. No bueno. DME is getting power, check engine light is working, but no ignition, no injector pulse, no fuel pump... nothing.

Check the power to all the sensors and solenoids. There is power to the injector plugs, the coils and the igniters.

Online it says to check the crank sensor. Not the problem. Checks out like the guys on the Rennlist 964 forum say it should. 5.5 volts AC at the DME plug. Spec is between 3v and 6v.

Check the hall effect sensor in the distributor. It is a 3 wire hall sensor, and the shield wire is also the ground wire. And there is no connection between the Hall sensor plug and pin 30 on the DME plug. So no signal.

Tomorrow morning I am going to put a temp wire between the DME and the hall sensor to connect the grounds back up. Maybe that will fix it.


Gotta get it running. I don't want to disappoint anyone.

(IMG:style_emoticons/default/smash.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Sep 1 2019, 08:55 PM
Post #189


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
So today's update...

Found out the DME is bad. Put the stock chip back in it for troubleshooting. Now the check engine light doesn't read codes. Online says the DME is bad if it does that. Trying to locate another one.

Pushed another liter of fluid through the brakes. Still no pedal. More details in my other thread.

Changed the clutch master cylinder. Ran out of day before I got it bled.

And my truck is trying to eat a left front wheel bearing.... so I have to do that tomorrow morning before anything else.

(IMG:style_emoticons/default/headbang.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
rick 918-S
post Sep 2 2019, 05:29 AM
Post #190


Hey nice rack! -Celette
***************

Group: Members
Posts: 20,427
Joined: 30-December 02
From: Now in Superior WI
Member No.: 43
Region Association: Northstar Region
Have a cup of coffee and relax for an hour. Fresh mind and you will get it sorted. Make a list and work thru it. (IMG:style_emoticons/default/idea.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
burton73
post Sep 2 2019, 11:29 AM
Post #191


burton73
****

Group: Members
Posts: 3,508
Joined: 2-January 07
From: Los Angeles
Member No.: 7,414
Region Association: Southern California
QUOTE(rick 918-S @ Sep 2 2019, 04:29 AM) *

Have a cup of coffee and relax for an hour. Fresh mind and you will get it sorted. Make a list and work thru it. (IMG:style_emoticons/default/idea.gif)


(IMG:style_emoticons/default/agree.gif) (IMG:style_emoticons/default/bye1.gif)
And do not forget to breath.

Bob B
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Sep 2 2019, 11:30 AM
Post #192


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
Fixed the truck wheel bearing. Got the brakes fixed on Igor. Got a replacement DME. So after I finish eating, I am back in the garage to see if it will run!!

Clay
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rusty
post Sep 2 2019, 06:21 PM
Post #193


Wanted: Engine case GA003709
*****

Group: Admin
Posts: 7,941
Joined: 24-December 02
From: North Alabama
Member No.: 6
Region Association: Galt's Gulch
QUOTE(ClayPerrine @ Sep 2 2019, 11:30 AM) *

Fixed the truck wheel bearing. Got the brakes fixed on Igor. Got a replacement DME. So after I finish eating, I am back in the garage to see if it will run!!

Clay


(IMG:http://www.914world.com/bbs2/uploads_offsite/giphygifs.s3.amazonaws.com-6-1567470079.1.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Sep 2 2019, 06:42 PM
Post #194


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
Keep waiting.

I was trying to fix the issue with the clutch hydraulics. I didn't try to start it. No point if the clutch won't disengage, and to work on the clutch, I have to work around the headers. I don't want them hot when I try that.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
76-914
post Sep 3 2019, 08:39 AM
Post #195


Repeat Offender & Resident Subaru Antagonist
**********

Group: Members
Posts: 13,494
Joined: 23-January 09
From: Temecula, CA
Member No.: 9,964
Region Association: Southern California
(IMG:style_emoticons/default/popcorn[1].gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Sep 4 2019, 08:39 PM
Post #196


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,416
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
Update: Sorry, no pictures. Too busy fixing shit.

Got really frustrated with the car.

Seems I had a mismatch between the clutch master and clutch slave. The master was too small to move the slave enough to disengage the clutch. Ordered the proper one from Summit. Hopefully here in the next day or so.

Worked on the DME issues tonight. Found I HATE Porsche for superseding the crank sensor with the one from the 993. It has a different plug, and I wired the plug up a year ago when I got to installing it on the engine. Well, I swapped the shield and signal wires, so the DME was not seeing the signal from the cranks sensor. Fixed that, and the fuel pump started to work when cranking. Fixed a minor fuel leak, and started testing ignition and injector pulse. I have ignition on one coil only. Swapped stuff around to verify the issue, and its not the wiring, it is the ignitor. Hopefully I can get one tomorrow.

Still no pulse at the injectors. Checked them and I have 12V to one side of all of them, and I have continuity back to the DME unit. I had to stop for the night

So the injector issue is next on the DME hit parade.

I am still pushing to make Okteenerfest!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Mblizzard
post Sep 4 2019, 09:11 PM
Post #197


Advanced Member
****

Group: Members
Posts: 3,033
Joined: 28-January 13
From: Knoxville Tn
Member No.: 15,438
Region Association: South East States
I feel your pain! Wishing you all the best. But the reality in doing what we love is that there are an incomprehensible number of variables in the effort success. You have to chase each one down and that consumes a lot of time. Keep going! Just in case I ordered a case of 914 bourbon to drown our sorrows.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rob-O
post Sep 4 2019, 09:33 PM
Post #198


Senior Member
***

Group: Members
Posts: 1,251
Joined: 5-December 03
From: Mansfield, TX
Member No.: 1,419
Region Association: Southwest Region
The experience you’re getting though is priceless.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rusty
post Sep 5 2019, 05:01 AM
Post #199


Wanted: Engine case GA003709
*****

Group: Admin
Posts: 7,941
Joined: 24-December 02
From: North Alabama
Member No.: 6
Region Association: Galt's Gulch
Hang in there buddy! (IMG:style_emoticons/default/beer.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
914dave
post Sep 5 2019, 05:28 AM
Post #200


914 Addict
***

Group: Members
Posts: 700
Joined: 19-October 03
From: Willow Grove Pa.
Member No.: 1,262
Region Association: North East States
Nothing like a deadline to motivate you. Looking forward to seeing the car.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
