> Project Thread Fredriks GT build, GT-build, rustoration, making parts and nerding out.
GTSandberg
post Sep 5 2019, 02:21 PM
Post #21


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(mb911 @ Sep 5 2019, 08:15 PM) *

Just a note as I have had made and sold 38 sets of GT hard lines the indent really is not required.. I had no issues fitting mine personally ..

Haha, that just makes the time spent on this even more worthwhile (IMG:style_emoticons/default/lol-2.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 5 2019, 02:23 PM
Post #22


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(defianty @ Sep 5 2019, 07:20 PM) *

Nice work, look forward to seeing more.

I may say exactly the same, just saw your own build thread, wow!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 6 2019, 08:11 AM
Post #23


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



The GT oil system is of course a challenge.

Attached Image
These are 3 vital components that are really difficult to come by/expensive

Luckily this is old school technology and possible to reverse engineer and replicate. At least the thermostate and oil pressure relief valve. Casting the oil filter bracket is a bit trickier, and most of them are magnesium also..

Attached Image
Thermostate housing 3D-model

Attached Image
OPR-valve 3D model (cast part)

Attached Image
3D-model of opr-assembly

Attached Image
Plugs (is it called that..?) for sand casting (I have a guy who is going to do the metal casting).

Work in progress, very exciting
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
jd74914
post Sep 6 2019, 09:34 AM
Post #24


Its alive
****

Group: Members
Posts: 4,458
Joined: 16-February 04
From: CT
Member No.: 1,659
Region Association: North East States



QUOTE(GTSandberg @ Sep 6 2019, 09:11 AM) *

Plugs (is it called that..?) for sand casting (I have a guy who is going to do the metal casting).

Work in progress, very exciting

That's awesome!! Very cool. Did you oversize them to allow for casting shrinkage? In the past I've had a number of parts sand cast and have had to oversize between 1.5-3% for different magnesium and aluminum alloys.

They are called plugs. (IMG:style_emoticons/default/smile.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Mueller
post Sep 6 2019, 09:45 AM
Post #25


914 Freak!
***************

Group: Members
Posts: 16,857
Joined: 4-January 03
From: Antioch, CA
Member No.: 87
Region Association: None



Impressive amount of sheet metal, and casting your own parts takes it up a notch for sure.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
tygaboy
post Sep 6 2019, 09:50 AM
Post #26


Advanced Member
****

Group: Members
Posts: 3,111
Joined: 6-October 15
From: Petaluma, CA
Member No.: 19,241
Region Association: Northern California



Stamping dies! (IMG:style_emoticons/default/aktion035.gif) Really impressive fabrication. Keep up the fabulous work.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
bbrock
post Sep 6 2019, 09:59 AM
Post #27


Advanced Member
****

Group: Members
Posts: 3,542
Joined: 17-February 17
From: Montana
Member No.: 20,845
Region Association: Rocky Mountains



What???!!! (IMG:style_emoticons/default/shocked[1].gif) Truly next level! (IMG:style_emoticons/default/pray.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
raynekat
post Sep 6 2019, 01:37 PM
Post #28


Senior Member
***

Group: Members
Posts: 1,693
Joined: 30-December 14
From: Portland, Oregon
Member No.: 18,263
Region Association: Pacific Northwest



QUOTE(GTSandberg @ Sep 6 2019, 07:11 AM) *

The GT oil system is of course a challenge.

Attached Image
These are 3 vital components that are really difficult to come by/expensive



Cool project.
This just happens to be on Ebay right now.
Not affiliated.

Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
sixnotfour
post Sep 6 2019, 03:56 PM
Post #29


914 Guru
*****

Group: Members
Posts: 9,490
Joined: 12-September 04
From: Life Elevated..planet UT.
Member No.: 2,744
Region Association: Rocky Mountains



you can get the thermo, with ear repo. germany and the preschona valve, germany and usa(armando) but you probably already knew that.. nice to have the capability to make these..

(IMG:style_emoticons/default/slap.gif) (IMG:style_emoticons/default/popcorn[1].gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:34 AM
Post #30


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(jd74914 @ Sep 6 2019, 03:34 PM) *

QUOTE(GTSandberg @ Sep 6 2019, 09:11 AM) *

Plugs (is it called that..?) for sand casting (I have a guy who is going to do the metal casting).

Work in progress, very exciting

That's awesome!! Very cool. Did you oversize them to allow for casting shrinkage? In the past I've had a number of parts sand cast and have had to oversize between 1.5-3% for different magnesium and aluminum alloys.

They are called plugs. (IMG:style_emoticons/default/smile.gif)


Thank you for the feedback!
I have compensated 1,1% in the model + a layer of filler.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:48 AM
Post #31


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(Mueller @ Sep 6 2019, 03:45 PM) *

Impressive amount of sheet metal, and casting your own parts takes it up a notch for sure.


Thank you, good to hear Im not the only one who finds fabrication inspiring (IMG:style_emoticons/default/smile.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:51 AM
Post #32


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(tygaboy @ Sep 6 2019, 03:50 PM) *

Stamping dies! (IMG:style_emoticons/default/aktion035.gif) Really impressive fabrication. Keep up the fabulous work.

Not the most sucessful/effiecient project with the dies, but I really enjoy the process of making things myself in the garage. (IMG:style_emoticons/default/welder.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:53 AM
Post #33


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(bbrock @ Sep 6 2019, 03:59 PM) *


Thank you (IMG:style_emoticons/default/biggrin.gif) (IMG:style_emoticons/default/biggrin.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:57 AM
Post #34


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(raynekat @ Sep 6 2019, 07:37 PM) *

QUOTE(GTSandberg @ Sep 6 2019, 07:11 AM) *

The GT oil system is of course a challenge.

Attached Image
These are 3 vital components that are really difficult to come by/expensive



Cool project.
This just happens to be on Ebay right now.
Not affiliated.

Attached Image


Thermostat is "missing" the mounting ear, but the bracket looks really nice. Seems to be a good price (but still a quite a lot of money).
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 07:59 AM
Post #35


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(sixnotfour @ Sep 6 2019, 09:56 PM) *

you can get the thermo, with ear repo. germany and the preschona valve, germany and usa(armando) but you probably already knew that.. nice to have the capability to make these..

(IMG:style_emoticons/default/slap.gif) (IMG:style_emoticons/default/popcorn[1].gif)


I have seen the preschona reproduction, but not the thermostat..
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 10 2019, 08:09 AM
Post #36


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



And then, some pictures of the brake set up. Not home made this, except the spacer inside the rear discs.

Attached Image
Standard 914 and the 914/6 GT

Attached Image
Spacer

Attached Image
rear assembly

Attached Image
Front setup (under construction..)

Attached Image
911 caliper and paper version of the spacer (IMG:style_emoticons/default/biggrin.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 11 2019, 07:35 AM
Post #37


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



I bought the project in 2012 (I think..) and most of the time from then to 2016, when I really started working on it again, has been used to ponder about color. The car is originally signal orange, a really cool color. However.. living in the worlds most sparsely populated country , there are not many 914 gt's around, and one of them is signal orange. I can guarantee this car and my car will meet on some cars and coffee in the future. So what else.
The car has been repainted ridiculosly many times and not much of the original paint is saveable, so I consider it a blank canvas.

Attached Image
I have never managed to figure out how many layers of paint there are.


Attached Image
I fell in love with the Sunoco/Duval livery, so I am quite sure it is going to be like this.

Attached Image
Even the cat seems to agree

Attached Image
I guess I am fully committed as it has been granted a spot in the living room as well (IMG:style_emoticons/default/cheer.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
mepstein
post Sep 11 2019, 08:04 AM
Post #38


914-6 GT in waiting
***************

Group: Members
Posts: 15,061
Joined: 19-September 09
From: Landenberg, PA/Wilmington, DE
Member No.: 10,825
Region Association: MidAtlantic Region



Sunoco/Duval livery - great choice.
I fduval is his son and 914world member.

http://www.914world.com/bbs2/index.php?sho...44&hl=Duval
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
GTSandberg
post Sep 12 2019, 07:35 AM
Post #39


Member
**

Group: Members
Posts: 59
Joined: 16-August 19
From: Drammen, Norway
Member No.: 23,373
Region Association: Europe



QUOTE(mepstein @ Sep 11 2019, 02:04 PM) *

Sunoco/Duval livery - great choice.
I fduval is his son and 914world member.

http://www.914world.com/bbs2/index.php?sho...44&hl=Duval



Interesting read in the link! I have had some contakt with Francois about the yellow color some time ago, very nice and helpful guy!
He thought the yellow was the yellow in the Sunoco logo. I have found some info about this online, and Sunoco had a RAL code in a document (RAL 1018)
This did not look right at all, to much green I think.

Attached Image
I painted the inside of the door to see, In my mind the part laying on top has a more similar color..

I have from other sources found other color codes that look better, more red in the yellow. I will try them out.
These are things that may have changed over time I suppose (new versions of the logo)..
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
defianty
post Sep 12 2019, 08:15 AM
Post #40


Senior Member
***

Group: Members
Posts: 652
Joined: 9-August 06
From: Essex, UK
Member No.: 6,621
Region Association: None



Looks like this is going to be a great build. I've almost finished mine and am already missing the research stage of the project, great fun.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
