 CAD profile of 914..., does anyone have one???? |
|
|
|
Porsche, and the Porsche crest are registered trademarks of Dr. Ing. h.c. F. Porsche AG.
This site is not affiliated with Porsche in any way. Its only purpose is to provide an online forum for car enthusiasts. All other trademarks are property of their respective owners. |
|
|
| BKLA |
 Jul 27 2006, 10:45 AM
Post
#1
|
|
Really old member  Group: Members Posts: 1,253 Joined: 14-August 05 From: OR Member No.: 4,590 Region Association: Pacific Northwest
 |
I am looking for a CAD file of the profile of a 914 to save me some time. I am looking into one of those garage lifts and I need to figure out clearances related to the 914 and obstructions (ducts, garage door opener, etc.) in my garage.
An eps file would be fine as well. (.dwg or .dxf formats are great!) .3ds file for a 3d file is great too. Thanks! (IMG:style_emoticons/default/biggrin.gif) |
   |

|
  |
Replies(1 - 3)
| Mueller |
Jul 27 2006, 10:56 AM
Post
#2
|
|
914 Freak! Group: Members Posts: 17,155 Joined: 4-January 03 From: Antioch, CA Member No.: 87 Region Association: None
|
seems like a lot of work to have to model the lift and garage (IMG:style_emoticons/default/smile.gif)
this'll get you some dimensions for quick referance: http://www.pelicanparts.com/literature/914_blueprint.htm do a search here, someone has some 3D models of a 914 that I think they are willing to share... |
|
|
|
| BKLA |
Jul 27 2006, 03:17 PM
Post
#3
|
|
Really old member Group: Members Posts: 1,253 Joined: 14-August 05 From: OR Member No.: 4,590 Region Association: Pacific Northwest
|
QUOTE(Mueller @ Jul 27 2006, 09:56 AM)  seems like a lot of work to have to model the lift and garage (IMG:style_emoticons/default/smile.gif) this'll get you some dimensions for quick referance: http://www.pelicanparts.com/literature/914_blueprint.htm do a search here, someone has some 3D models of a 914 that I think they are willing to share... Naw.. I'm just drafting up a section thru the garage to see if everything will clear and fit.... Thanks for the link. The jpg file will be fine as it has dimensions on it! WaHoo! (IMG:style_emoticons/default/aktion035.gif) |
|
|
|
| marks914 |
Jul 29 2006, 04:55 AM
Post
#4
|
|
Senior Member Group: Members Posts: 845 Joined: 9-October 04 From: the motor city Member No.: 2,912 Region Association: None |
I have this one as an .iges file. What software are you using? iges is pretty much the jpeg of 3d, pretty much any program can open it.
Mark Attached image(s)
|
|
|
|
|
