 20 year hibernation, she lives to tell another tale! (1/13/13) |
|
|
|
Porsche, and the Porsche crest are registered trademarks of Dr. Ing. h.c. F. Porsche AG.
This site is not affiliated with Porsche in any way. Its only purpose is to provide an online forum for car enthusiasts. All other trademarks are property of their respective owners. |
|
|
  |
| dfelz |
 Jul 12 2012, 08:25 PM
Post
#1
|
|
beach bum  Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
 |
The engine in my 72 1.7L hasn't been driven in 20 years, (IMG:style_emoticons/default/chair.gif) and I want to start prepping the engine to come back to life! I have a general plan to get it running and want to share it, but would really like tips and to-do's while i get this under way since i have never taken on a project like this before.
My plan so far: New gas tank, SS lines, fuel pump, fuel filter (order and on the way) Rebuild kit with new gaskets and such for each carb, will thoroughly clean them out in that process as well New Bosch spark plugs and spark plug wiring set New distributor, (looking at AAs R0231178009) New battery and battery terminals Oil change and new oil filter If anyone thinks that there is some thing must be added to this list prior to me even attempting the first crank please let me know! All suggestions are welcome! Thanks!! (IMG:style_emoticons/default/beerchug.gif) |
   |

|
| mrbubblehead |
Jul 12 2012, 08:42 PM
Post
#2
|
|
Twodollardoug Group: Members Posts: 1,155 Joined: 17-December 10 From: calimesa ca. Member No.: 12,492 Region Association: Southern California |
QUOTE(dfelz @ Jul 12 2012, 07:25 PM)  The engine in my 72 1.7L hasn't been driven in 20 years, (IMG:style_emoticons/default/chair.gif) and I want to start prepping the engine to come back to life! I have a general plan to get it running and want to share it, but would really like tips and to-do's while i get this under way since i have never taken on a project like this before. My plan so far: New gas tank, SS lines, fuel pump, fuel filter (order and on the way) Rebuild kit with new gaskets and such for each carb, will thoroughly clean them out in that process as well New Bosch spark plugs and spark plug wiring set New distributor, (looking at AAs R0231178009) New battery and battery terminals Oil change and new oil filter If anyone thinks that there is some thing must be added to this list prior to me even attempting the first crank please let me know! All suggestions are welcome! Thanks!! (IMG:style_emoticons/default/beerchug.gif) i would pull the spark plugs and crank it untill the oil pressure light goes out. |
|
|
|
| Mike Bellis |
Jul 12 2012, 08:42 PM
Post
#3
|
|
Resident Electrician Group: Members Posts: 8,347 Joined: 22-June 09 From: Midlothian TX Member No.: 10,496 Region Association: None
|
Change all the rubber fuel hoses. Use correct FI hose and clamps.
|
|
|
|
| mrbubblehead |
Jul 12 2012, 08:46 PM
Post
#4
|
|
Twodollardoug Group: Members Posts: 1,155 Joined: 17-December 10 From: calimesa ca. Member No.: 12,492 Region Association: Southern California |
also.... if your running carbs and thinking about buying a new dizzy. you should definately think about an SVDA dizzy. http://vwparts.aircooled.net/Aircooled-Net...-p/acn-svda.htm
|
|
|
|
| Rusty |
Jul 13 2012, 09:40 AM
Post
#5
|
|
Wanted: Engine case GA003709 Group: Admin Posts: 7,959 Joined: 24-December 02 From: North Alabama Member No.: 6 Region Association: Galt's Gulch
|
A squirt of oil in each of the cylinders before you start turning the engine over wouldn't be a bad idea.
|
|
|
|
| dfelz |
Jul 18 2012, 07:33 PM
Post
#6
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
QUOTE(Rusty @ Jul 13 2012, 08:40 AM) A squirt of oil in each of the cylinders before you start turning the engine over wouldn't be a bad idea. do i need to drop the engine out to do this? |
|
|
|
| Rusty |
Jul 18 2012, 07:39 PM
Post
#7
|
|
Wanted: Engine case GA003709 Group: Admin Posts: 7,959 Joined: 24-December 02 From: North Alabama Member No.: 6 Region Association: Galt's Gulch
|
QUOTE(dfelz @ Jul 18 2012, 07:33 PM) QUOTE(Rusty @ Jul 13 2012, 08:40 AM) A squirt of oil in each of the cylinders before you start turning the engine over wouldn't be a bad idea. do i need to drop the engine out to do this? No, sir. Pull your plugs one at a time and squirt about a teaspoon of oil into each cylinder. Make sure it gets into the cylinder and not just into the engine tin. (IMG:style_emoticons/default/biggrin.gif) |
|
|
|
| ottox914 |
Jul 20 2012, 01:49 PM
Post
#8
|
|
The glory that once was. Group: Members Posts: 1,302 Joined: 15-December 03 From: Mahtomedi, MN Member No.: 1,438 Region Association: Upper MidWest |
If you have the trans in neutral, and grab the fan, with the plugs out, can you turn it over? I have put a good shot of WD40 or other spray lube in the plug holes- DON'T LET THE PLASTIC STRAW/SPOUT THINGY COME OFF THE BOTTLE AND GET LOST IN THE ENGINE. Then I'll spin it over by hand, and repeat. Spinning with the battery and starter till the oil pressure light on the dash goes out is a good next step. You could stick a plug in a wire and ground it, to see if the existing dizzy will make a spark.
IF you do put the plugs back in and turn it over, expect insect control fog out the back, given the oil in the cyls. Fire it up outside the garage. Don't think just leaving the door open will be OK. When/if it starts, if it makes $$$ sounding noise, shut it down. If it just rattles and bangs like an air cooled engine, great. Shut it down and change oil and filter, cuz you contaminated it with the WD, and any rust/crud or condensation in the case had contaminated it. IF the tank isn't totally roached, I'd just pull it and rinse it out. With the tank out, you disconnect the fuel lines in the engine compartment and use some air to blow the fuel lines in the tunnel out. New fuel filter seems a cheep and reasonable step. Does the current fuel pump work? Has it been tested? Just trying to save ya a few bucks if any of these parts are still good. Good luck and let us know how it goes! |
|
|
|
| Rusty |
Jul 20 2012, 02:00 PM
Post
#9
|
|
Wanted: Engine case GA003709 Group: Admin Posts: 7,959 Joined: 24-December 02 From: North Alabama Member No.: 6 Region Association: Galt's Gulch
|
QUOTE DON'T LET THE PLASTIC STRAW/SPOUT THINGY COME OFF THE BOTTLE AND GET LOST IN THE ENGINE. Exactly. the only thing that could be worse is if you had a tip of a chopstick break off when finding TDC on #1. (IMG:style_emoticons/default/av-943.gif) |
|
|
|
| skaufmann |
Jul 20 2012, 02:20 PM
Post
#10
|
|
Blissfully Ignorant Group: Members Posts: 103 Joined: 26-May 11 From: San Diego - College Area Member No.: 13,123 Region Association: Southern California |
QUOTE(Rusty @ Jul 13 2012, 08:40 AM) A squirt of oil in each of the cylinders before you start turning the engine over wouldn't be a bad idea. I used Marvel Mystery oil too. Used one of those baby medicine syringes to squirt the oil in. It helped to get passed the tins. I also changed oil with a high-zinc oil initially. Once you get it running you'll want to change it again. If you're at all concerned about the cylinders locked up, a gentler approach is get one back wheel off the ground with it in gear and hand turn the engine via the wheel after you squirt oil in it with no plugs. Let it sit a day or so (with plugs so nothing gets in) and do it again. After another day I'd say give it a crank and get oil system pressurized. The brakes will be that other thing you need to address. Getting Mo is one thing. Getting it No-Mo is another and purely a safety thing. |
|
|
|
| dfelz |
Aug 1 2012, 12:11 AM
Post
#11
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
QUOTE(ottox914 @ Jul 20 2012, 12:49 PM) Does the current fuel pump work? Has it been tested? Just trying to save ya a few bucks if any of these parts are still good. Good luck and let us know how it goes! Thanks for all the tips, i hope i get to this point soon, I am still working on redoing the suspension to 911 set up. But the PO said the FP went out 10+ years ago, but i havent tested it myself. I already have a new tank, SS lines, fuel filter, and fuel pump ready to be installed. |
|
|
|
| dfelz |
Dec 30 2012, 04:38 AM
Post
#12
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
Alright! Well it has been some time since I have updated this or any other progress thread of mine but it has not been in vain. (IMG:style_emoticons/default/stirthepot.gif) This past quarter at school was a tough one and very time consuming, so not many man hours were spent in my garage. But over the past few months I have been collecting both new and used parts for the car, way to many to list.
Onto the important shit, the engine has still not been started, but it does work, I think. It turns over nicely and is not frozen. All the electronics seemed to be working for the most part in order. I have all the parts needed to switch out the fuel system. Got the kit from Tangerine Racing. My biggest question is the schematic of it all. The fuel pump is one in and one out and meant to be up front for relocation, so how does the return line on the tank tie into things??? I was originally thinking from tank sending outlet to filter to pump to tunnel line to engine compartment line to fuel pressure regulator to a tee and then to each carb. Is this ok!?!? Or do i have to tee from the regulator to both carbs and a return line to tank? Thanks in advance! (IMG:style_emoticons/default/beerchug.gif) David |
|
|
|
| dfelz |
Dec 30 2012, 04:42 AM
Post
#13
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
A few more small questions!
What does the fuel pump positive wire look like and where should I look to locate it? Where does the green wire from the distributor go? Why do the new Bosch Super Spark plugs i ordered not fit in the stock connectors (they were purchased from AA, and the exact same ones were listed on pelican and other sites to fit my car (IMG:style_emoticons/default/bs.gif) )? I believe they are the WC77... I'll have to check though. Is there any way to get the spark plugs out without removing the covering/cooling tins? Thats all i can think of right now, I'm tired!! (IMG:style_emoticons/default/bye1.gif) |
|
|
|
| mepstein |
Dec 30 2012, 08:19 AM
Post
#14
|
|
914-6 GT in waiting Group: Members Posts: 19,846 Joined: 19-September 09 From: Landenberg, PA/Wilmington, DE Member No.: 10,825 Region Association: MidAtlantic Region
|
QUOTE(dfelz @ Dec 30 2012, 05:42 AM) A few more small questions! What does the fuel pump positive wire look like and where should I look to locate it? Where does the green wire from the distributor go? Why do the new Bosch Super Spark plugs i ordered not fit in the stock connectors (they were purchased from AA, and the exact same ones were listed on pelican and other sites to fit my car (IMG:style_emoticons/default/bs.gif) )? I believe they are the WC77... I'll have to check though. Is there any way to get the spark plugs out without removing the covering/cooling tins? Thats all i can think of right now, I'm tired!! (IMG:style_emoticons/default/bye1.gif) You have to unscrew the small cap on top of the spark plug to get it to fit the wires. |
|
|
|
| brenz |
Dec 30 2012, 09:46 AM
Post
#15
|
|
Member Group: Members Posts: 56 Joined: 10-March 10 From: Delaware, USA Member No.: 11,451 Region Association: MidAtlantic Region |
Fuel pump positive wire is black with a red band on my 75. Ground is brown. Not sure where to find it on a 72 though.
The green wire from the distributor goes to the negative side of the ignition coil. Might be marked with a #1 for neg., #15 for positive. Spark plugs should come out without removing the tin. They sit at an odd angle. Use a quality socket and and 3" extension. Make sure the socket is seated on the plug by hand and then go easy with the ratchet. Once it starts turning I usually turn the extension by hand to be sure it backing out ok. When putting them back use anti-sieze on the threads and start them by hand. |
|
|
|
| oldschool |
Dec 30 2012, 02:05 PM
Post
#16
|
|
Advanced Member Group: Members Posts: 3,373 Joined: 29-October 08 From: P-town Member No.: 9,705 Region Association: Southern California |
Hey I have a 1.7 sitting in my garage I may be able to help you out.btw I'm in Pomona also.
|
|
|
|
| dfelz |
Dec 30 2012, 03:57 PM
Post
#17
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
QUOTE(brenz @ Dec 30 2012, 07:46 AM) Fuel pump positive wire is black with a red band on my 75. Ground is brown. Not sure where to find it on a 72 though. The green wire from the distributor goes to the negative side of the ignition coil. Might be marked with a #1 for neg., #15 for positive. Spark plugs should come out without removing the tin. They sit at an odd angle. Use a quality socket and and 3" extension. Make sure the socket is seated on the plug by hand and then go easy with the ratchet. Once it starts turning I usually turn the extension by hand to be sure it backing out ok. When putting them back use anti-sieze on the threads and start them by hand. Thanks brenz, I will have to look around for that black/red wire. I believe I saw it but the PO had cut it and attached it directly to the positive battery terminal.. so i may have to reattach it the relay board right? I'm going to leave those plugs in there for now then cause i dont think i have a deep enough socket that size, my roommate may though, ill ask him once he is home later in the week. and anti-sieze is now on my shopping list! QUOTE(oldschool @ Dec 30 2012, 12:05 PM) Hey I have a 1.7 sitting in my garage I may be able to help you out.btw I'm in Pomona also. I really appreciate that! It's comforting to know there is someone 'up the road' from me that can be of assistance if i get stuck. I am located in Walnut right off the 60 at brea canyon and go to school at cal poly pomona. Anyone know about plugging the return pipe on the gas tank??? (as mentioned in my fuel plan a few posts above???) |
|
|
|
| Series9 |
Dec 30 2012, 04:05 PM
Post
#18
|
|
Lesbians taste like chicken. Group: Members Posts: 5,446 Joined: 22-August 04 From: DeLand, FL Member No.: 2,602 Region Association: South East States |
Attached image(s)
|
|
|
|
| oldschool |
Dec 30 2012, 04:44 PM
Post
#19
|
|
Advanced Member Group: Members Posts: 3,373 Joined: 29-October 08 From: P-town Member No.: 9,705 Region Association: Southern California |
QUOTE(dfelz @ Dec 30 2012, 01:57 PM) QUOTE(brenz @ Dec 30 2012, 07:46 AM) Fuel pump positive wire is black with a red band on my 75. Ground is brown. Not sure where to find it on a 72 though. The green wire from the distributor goes to the negative side of the ignition coil. Might be marked with a #1 for neg., #15 for positive. Spark plugs should come out without removing the tin. They sit at an odd angle. Use a quality socket and and 3" extension. Make sure the socket is seated on the plug by hand and then go easy with the ratchet. Once it starts turning I usually turn the extension by hand to be sure it backing out ok. When putting them back use anti-sieze on the threads and start them by hand. Thanks brenz, I will have to look around for that black/red wire. I believe I saw it but the PO had cut it and attached it directly to the positive battery terminal.. so i may have to reattach it the relay board right? I'm going to leave those plugs in there for now then cause i dont think i have a deep enough socket that size, my roommate may though, ill ask him once he is home later in the week. and anti-sieze is now on my shopping list! QUOTE(oldschool @ Dec 30 2012, 12:05 PM) Hey I have a 1.7 sitting in my garage I may be able to help you out.btw I'm in Pomona also. I really appreciate that! It's comforting to know there is someone 'up the road' from me that can be of assistance if i get stuck. I am located in Walnut right off the 60 at brea canyon and go to school at cal poly pomona. Anyone know about plugging the return pipe on the gas tank??? (as mentioned in my fuel plan a few posts above???) ha ha so does the 914kid he has a yellow 914 with a black hood....super cool cat. |
|
|
|
| dfelz |
Dec 30 2012, 09:56 PM
Post
#20
|
|
beach bum Group: Members Posts: 419 Joined: 7-June 12 From: San Diego Member No.: 14,538 Region Association: Southern California
|
QUOTE(oldschool @ Dec 30 2012, 02:44 PM) ha ha so does the 914kid he has a yellow 914 with a black hood....super cool cat. Ya i see his car on campus all the time in the parking structure. I tried contacting him through this site, but he never responded.... |
|
|
|
|
