 Attaching Fiberglass rocker panels, Do you attach the top edge only? or do you screw in the bot as well? |
|
|
|
Porsche, and the Porsche crest are registered trademarks of Dr. Ing. h.c. F. Porsche AG.
This site is not affiliated with Porsche in any way. Its only purpose is to provide an online forum for car enthusiasts. All other trademarks are property of their respective owners. |
|
|
  |
| cobra94563 |
 May 31 2007, 10:15 AM
Post
#1
|
|
Chris  Group: Members Posts: 341 Joined: 1-March 05 From: San Francisco Member No.: 3,696  |
I'm attaching flared FG rocker panels.
I attached the top edge along the door sill and at the fenders and wondering if I should tap screw in the bottom edge as well? If anyone done this, thanks. (IMG:style_emoticons/default/confused24.gif) |
   |

|
| SGB |
May 31 2007, 10:35 AM
Post
#2
|
|
just visiting Group: Members Posts: 4,086 Joined: 8-March 03 From: Huntsville, AL Member No.: 404 Region Association: South East States |
I don't think you should penetrate the floor pan. What I did was drill a hole in the bottom edge of the rocker and attach (are you ready?) a binder clip so I can clip it to the ridge where the floor meets the long. I know it sounds pretty hokey, but it works. I'll try to take a picture tonight.
|
|
|
|
| So.Cal.914 |
May 31 2007, 10:47 AM
Post
#3
|
|
"...And it has a front trunk too." Group: Members Posts: 6,588 Joined: 15-February 04 From: Low Desert, CA./ Hills of N.J. Member No.: 1,658 Region Association: None |
If my memory is not fuching with me the stock one does secure to the bottem with screws.
|
|
|
|
| 1970 Neun vierzehn |
May 31 2007, 10:49 AM
Post
#4
|
|
Advanced Member Group: Members Posts: 3,199 Joined: 16-March 06 From: cincinnati, ohio Member No.: 5,727 |
Chris,
I had F/G rocker panels on my '70/4 from 1978 thru last year. They were not flared however. I fastened them with small sheetmetal screws where the rocker panel was secured previously with pop rivets on the door sill. I did not fasten them on the bottom, however.Those rocker panels never gave me any problems for almost 20 years. |
|
|
|
| 1970 Neun vierzehn |
May 31 2007, 10:50 AM
Post
#5
|
|
Advanced Member Group: Members Posts: 3,199 Joined: 16-March 06 From: cincinnati, ohio Member No.: 5,727 |
QUOTE(So.Cal.914 @ May 31 2007, 08:47 AM)  If my memory is not fuching with me the stock one does secure to the bottem with screws. Correct! |
|
|
|
| cobra94563 |
May 31 2007, 10:51 AM
Post
#6
|
|
Chris Group: Members Posts: 341 Joined: 1-March 05 From: San Francisco Member No.: 3,696 |
OK.
Also, as I attached the upper edge, the bot pulled away from the body, so it kind of goes straigh down. I have to push it in to attach and I don't know what it normally should be - angled or staright down? |
|
|
|
| So.Cal.914 |
May 31 2007, 11:16 AM
Post
#7
|
|
"...And it has a front trunk too." Group: Members Posts: 6,588 Joined: 15-February 04 From: Low Desert, CA./ Hills of N.J. Member No.: 1,658 Region Association: None |
It's angled.
 |
|
|
|
|
