Welcome to my Audi Turbo 914 build thread! This first post has been highly edited for your(and my) ease of navigation.
`
(IMG:http://www.914world.com/bbs2/uploads/post-172-1428991066.jpg)
`
The car 1973 Porsche 914 1.7 w/ appearance group package
(IMG:http://www.914world.com/bbs2/uploads/post-172-1429499049.jpg)
`
The Story:
I purchased this car when I was 14years old and had bought 2 other 914s with it for a measly $1100, The other 2 914’s were basket cases and one had been in a roll over. The previous owner put the 2.0 from the roll over car in this car. I parted out the other two cars and DID A V8 CONVERSION on mine after I couldn’t figure out how to adjust the valves (It seemed easier..). I do a 5 lug conversion as well as put some fiberglass flares on the car and many other things before I decide to paint the car. That is the start of this thread.
(IMG:http://www.914world.com/bbs2/uploads_offsite/i1210.photobucket.com-172-1295463716.1.jpg)
`
Next I decide that I don’t like how the v8 drives and how I could never keep it cool so I decide to embark on a journey with an engine I was already more familiar with. The Audi 1.8T.
To start at the 1.8T engine conversion click below.
http://www.914world.com/bbs2/index.php?sho...4780&st=309

Details on the car:
Engine: Audi AEB 1.8t Engine, Fully rebuilt, balanced rotating assembly and blueprinted, balanced and clearanced Intermediate shaft.
Crankshaft: Stock/polished
Rods: Scat Forged I beam rods
Pistons: Stock
Cams: Stock
Valves: Stock intake, Stainless nitrite coated Supertech exhaust AEVN-1103
Valve springs: Supertech high rpm valves SPRK-AUDI18
Piston rings: Goetze 08-502900-00 (Factory stock)
Head gasket: Elring Stock head gasket
Rod bearings: 034 Dry film coated bearings 034-202-1008
Crank bearings: 034 Dry film coated bearings 034-202-1000
Intake Manifold: Stock
Throttle Body: Stock AWM
Exhaust Manifold: APR Iconel Stage 3 manifold
Exhaust: 3" turbo back stainless steel w/ 2 stainless resonators
Intercooler: 700hp air to water core.
Turbo: Comp Turbo triple ball bearing CTB5356
Injectors: Bosch 550CC injectors ported and flow matched to 1300CC
Fuel Pump: Bosch 044 inside 034 Surge tank
Fuel rail: Stock fed with AN10 line
Water pump: Davies Craig EWP150 w/ LCD controller
MAF: PMAS HPX MAF in 3" housing
Boost controller: Cortex EBC

Transmission: Audi A4 1.8 5 speed code EHV FWD unit
100mm stub axles from boxster transmission
eBay sprung type LSD


Wiring: Strip all Porsche wiring, Replace with Audi wiring 100%
Engine Management: Modified OEM Audi Ecu
Power brakes: Not yet
ABS integration: Not yet
Traction control integration: Not yet
Launch control: Not yet
Cruise control: Yes
Climate control/AC: Yes
OBD2 full control: Yes
Check engine light: No smile.gif
Front trunk and rear trunk: YES!


8psi: 240whp (Canyon and autox setting)
14psi: 280whp (Street)
17PSI: 300whp (Track and Street driving) (Estimated power goal)
30psi(E85): 400whp (Full tilt mode)


Suspension:
Raised 911 spindals up front with Koni yellows
Mueller Roller Needle Bearings front and rear in leu of all bushings
Turbo tie rods
22mm Torsion bars
Nascar front sway bar
Koni yellows rear
911 rear hubs with 100mm studs
Ground control coil over kit in rear
225lb springs

Brakes:
911 A calipers front
Stock 914 rear calipers
Vented rotors front and rear
Porterfield semi race pads
19mm M/C
Proportioning valve replaced with T

Wheels:
Boxter rear 17 x 8.5 twists up front with 245 40 17
911 turbo 18 x 10 turbo twists in back with 285 35 18

Body:
Rich Bontempi HPH Flares Front and Rear, Molded
916 front and rear bumpers (front bumper to be reworked completely)
6" ducktail spoiler with supports
Engman long stiffening kit
Seam welded rear
Camp 914 hood shocks rear
Camp 914 Euro front turn signals
Bike rack (IMG:style_emoticons/default/biggrin.gif)

Interior(In Progress):

Fully custom interior (Still in design phase)
Harness Bar
5 point Cam lock harnesses
Pepboys Corbeau style seats





~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Now that the intro is done, here is my checklist of things that I want to get done with it.

Register *5-15-11*
Fix ignition **5-30-11**
Tune (again) ecu ** Converted back to Carbs after ECU died 5-30-11**
Clean goo in trunk (pic)
Install Dr window crank *5-30-11*
Change oil ****Finished 1-29-11****
Change water pump *Received Remanufactured pump from Slits 1-26-11****Finished Install w/ hangups 1-29-11****
Flush coolant
Finish targa bar S *Started progress on the bar*
Dr front 1/4 *Sand day 1 1-29-11* *Bondo Day 2-1-11**Primer Day 2-19-11*
Dr door *Sand day 1 1-29-11**Bondo Day 2-1-11*[/url]*Primer Day 2-19-11*
Rocker pannels *5-7-11*
Dr rear 1/4 *Sand day 1 1-29-11**Bondo Day 2-1-11*[/url]*Primer Day 2-19-11*
Trunk *Removed spoiler, Plugged old spoiler holes, Long board sanded trunk*
Rear bumper *Page 8*
Pass rear 1/4 *4-17-11*
Pass door *4-17-11*
Pass front 1/4 *4-17-11*
Front bumper *5-5-11*
Hood *Primer 5-2-11* *Paint 5-15-11*
Top *5-4-11[url=http://www.914world.com/bbs2/index.php?showtopic=114780&st=120#]
Primer sealer *5-15-11*
Paint *5-15-11*
Radiator cutouts in wheel well (And replace hood with stock) ***Completed 1-26-11***
Fix headlights *6-8-11*
Fix horn
Finish seat install ****Progress 1-19-11**** ***Finished 1-26-11***
Finish carpet *6-8-11*
Finish front sway bar
Fix Dr Door handle

This post has been edited by Andyrew: Jan 15 2022, 09:16 PM
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
44 Pages V « < 15 16 17 18 > »
Reply to this topicStart new topic
Replies(309 - 328)
Andyrew
post Apr 13 2015, 10:49 PM
Post #310


Spooling.... Please wait
**********

Group: Members
Posts: 13,380
Joined: 20-January 03
From: Riverbank, Ca
Member No.: 172
Region Association: Northern California



9000th post!

I took delivery of the Fiesta ST in early Dec and have been driving it like mad! I have confirmed it is everything through the twisties that I want it to be, and that has confirmed for me what I want to do with the 914.

Its time to go ahead and proceed with something different! I am going to do the same engine conversion that Mike Bellis has. The Audi/VW 1.8 turbo. I will not be doing a 6 speed swap at this time, however I am going to be using the v6 transmission so I have a bit longer gearing, and combining that with my taller tires should yield an acceptable cruising rpm.
First stage will be to mock up and install the engine/trani setup similar to Mike's. Second state will be strip the car of its wiring and replace it all with the Audi's wiring. Then mock up and install the pedal cluster with the brake reservoir (That'll be a bit of a challenge), cutting down the Audi dash, and figuring a way to make the climate control work. It'll be a long arduous process that'll probably take years, but at this rate its either this, the car sits for more years and I drive the Fiesta (Since its a hoot), or I sell it.
Im going to take my time with it and do it right. I want to be able to drive this thing coast to coast sometime.

Im going to be funding this partly with painting some cars in the downtime


Engine: Audi AEB 1.8t Engine, rebuild unit and install upgraded rods for 600hp capacity
Transmission: Audi A6 2.8 5 speed FWD unit
Turbo: Comp Turbo triple ball bearing CTB5356 10psi 275hp, 35psi 500+hp.
Wiring: Strip all Porsche wiring, Replace with Audi wiring 100%
Engine Management: Modified OEM Audi Ecu
Power brakes: Yes
ABS integration: Yes
Traction control integration: Yes
Launch control: Yes
Cruise control: Yes
Climate control/AC: Yes
Alarm: Yes
OBD2 full control: Yes
Check engine light: No (IMG:style_emoticons/default/smile.gif)
Front trunk and rear trunk: YES!

Looking forward to this!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Andyrew
post Apr 13 2015, 11:57 PM
Post #311


Spooling.... Please wait
**********

Group: Members
Posts: 13,380
Joined: 20-January 03
From: Riverbank, Ca
Member No.: 172
Region Association: Northern California



Photo of the Snail that is going on this engine vs the factory snail. I actually drove it like this at 10psi for about 5k miles before developed an oil leak (ended up being the oil filter sandwich plate... $5 fix) that parked the car for a year and I went back to stock.
